Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-18123876009
| Model Name | 156UCT double blind plug 4K touch |
| Panel manufacturer | Sharp |
| Display size | 15.6″ LED backlight |
| Product resolution | 3840*2160 |
| Display area | 345.6(W)×194.4(H) mm |
| Surface treatment | Matte |
| Display mode | IPS |
| brightness | 220cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (transmission) |
| Reaction time | 25 (Typ.)(Tr Td) ms |
| Touch function | Full glass touch |
| Pixel pitch | 0.108×0.108 (H×V) [235PPI] |
| screen ratio | 16:09 |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Refresh rate | 60Hz |
| Color gamut | 100% sRGB |
| HDR image rendering | YES |
| FREE-SYNC | YES |
| Display color | 16.7M |
| Mini HDMI | 2.0 input/audio and video transmission |
| USB Type C | External power supply/audio and video transmission |
| USB Type C | External power supply/audio and video transmission |
| Headphone plug | 3.5mm headphone jack |
| Key mode | Full-featured pulsator button |
| Appearance material | CNC aluminum alloy oxidation process (black background and bright edges) |
| physical dimension | 363*223*6(10)mm |
| Packing box size | 400*275*60mm |
| Bare metal weight | 1030g |
| Package weight | 2239g |
| Outer packing box | 7PCS/box |
| PS4 | Mini HDMI to HDMI |
| X BOX ONE | Mini HDMI to HDMI |
| SWITCH | Mini HDMI to HDMI Type-C one-line direct connection |
| tablet | Some models Type-C direct connection |
| PC host | Mini HDMI to HDMI |
| notebook | Mini HDMI to Mini HDMI Type-C one-line direct connection |
| TV box | Mini HDMI to HDMI |
| Digital camera | Mini HDMI to HDMI |
| Android phone | Samsung/Huawei/JMGO and other full-featured phones Mobile phone mode/PC mode power supply |
