Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
| Model Number | ZT19MC |
|---|---|
| Touch screen monitor | Resistance |
| Resolution | 1280*1024 |
| colour | black |
| Interface Type | VGA USB HDMI optional |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-18123876009
| LCD Type | 19” TFT-LCD | Luminance(cd/m2) | 350, 1000cd/m2 – optional |
| Video Input | VGA and DVI , HD MI – optional | Response Time(Rising/Falling) | 5s/5s |
| OSD controls | Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | Support Color | 16.7M colors |
| Mount Interface | 1)VESA 75mm and 100mm | Backlight MTBF(hr) | 30000 |
| 2)Mount bracket, horizontal or vertical | Touchscreen Specification | ||
| Active Area(mm) | 378.3(H)×303.0(V) | Type | RESISTIVE Touch screens |
| Resolution | 1280×1024@75Hz | Resolution | 4096*4096 |
| Dot Pitch(mm) | 0.294×0.294 | Light Transmission | 92% |
| Viewing angle (v/h) | 176°/170° | Touch Life Cycle | 50 millions |
| Contrast | 1000:1 | Touch Response time | 2ms |
| Touch System Interface | USB/RS232 interface | ||
