Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
| Model Number | ZT22R |
|---|---|
| Touch screen monitor | Resistance |
| Resolution | 1920×1080 |
| colour | black |
| Interface Type | VGA USB HDMI optional |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-18123876009
| Panel size | 21.5 inch TFT-LCD Industrial Grade Touch Screen Monitor | ||
| Display ratio | 16:09 | Touch model | 4-wire resistive touch |
| Standard Resolution | 1920*1080/60HZ | Optional | (two point infrared touch optional) |
| Number of Colors | 16.7M | Duration | 50000hours |
| Brightness | 450cd/m2 | touch validity | >1,000,000 |
| Response time | 5ms | Mount (optional) | 1) provide wall brackets for wall-mounting, VESA 75mm&100mm |
| View angle | Horizontal: 160° | 2) provide stable metal base to support the monitor | |
| Vertical: 150° | OSD control | AUTO,+,POWER,-,MENU | |
| Contrase ratio | 1000/1 | brightness,contrast ratio,auto adjustment,phase position,clock,Languages,function,Install,reset | |
| Video input format | (analog) RGB | Touch interface | USB or RS232 optional |
| Interface | VGA for video signal | Touch response time | 5ms |
| HD-MI, AV, TV, USB, BNC, DVI optional | Warranty | 3 year,provide spare parts | |
| Frequency | HSF:30-80KHZ VSF:56-75HZ | Supporting O.S | Windows,Linux,Mac. |
| Operation Environment | Workable Temperature:-10 to 60°C Storage temperature:-20 to 70°C | Power supply | External Power Supply:100 to 240V (DC 12V) |
