Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Shenzhen, China
OEM or ZWBA
CE ROHS
2-8 working days
2
| Model Number | ZT1097C |
|---|---|
| Screen Size | 10 inch |
| Touch screen monitor | Capacitive Screen |
| Resolution | 1024*768 |
| colour | black |
| Interface Type | VGA USB HDMI optional |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-18123876009
| Panel size | 10 inch IPS Touch Screen Monitor | Touch model | Projected Capacitive touch screen | |
| Display area | 200.91(W)×152.27(H) mm | Optional | (resistive touch,SAW,Infrared touch,etc optional) | |
| Standard Resolution | 1024*768 | Duration | 50000hours | |
| Number of Colors | 16.2M | touch validity | >1,000,000 | |
| Brightness | 300cd/m2 | Net weight | 2.0 Kgs/pcs,include foladable stander | |
| Response time | 5ms | Gross weight | 2.5 Kgs/pcs,include foladable stander | |
| View angle | Horizontal:178° | Power consumption | 18W | |
| Vertical:178° | Setup (optional) | 1) provide wall brackets for wall-mounting, VESA 75mm&100mm | ||
| Contrase ratio | 1000:01:00 | 2) provide foladable stander to support the monitor | ||
| Connector | VGA for video signal | OSD control | AUTO,+,POWER,-,MENU | |
| USB (or RS232) for touch | brightness,contrast ratio,auto adjustment,phase position,clock,Languages,function,Install,reset | |||
| Frequency | 30~80KHz/60~75Hz | Touch interface | USB or RS232 optional | |
| Power supply | External Power Supply:100 to 240V (DC 12V) | Touch response time | 5ms | |
| Operation Environment | Workable Temperature:-10 to 60°C Storage temperature:-20 to 70°C | Certificate | CE, ROHS | |
| Operate relative humidity:20% to 80%;storage relative humidity:10% to 90% | Warranty | 3 years warranty |
